« ELECTRICAL CONNECTIONS

Crimp & Seal

CRIMP & SEAL insulates and protects electrical connections from mechanical abuse and wire pull-out.
CRIMP & SEAL provides a tough, environment friendly sealed wire connection. Their crimp barrel or terminal, encased in a rugged nylon tubing with a special hot-melt adhesive, resists damage from abresions and cuts.
CRIMP & SEAL retains its flexibility and impact-resistance long after similar products have become brittle.
The colours of CRIMP & SEAL are coded to easily identify the wire diameter, yet they are transparent for the inspection of the finished connection.

  • Cable connector provided with wear-resistant nylon insulation and meltable adhesive.
  • Shrink ratio of the insulation 2:1.
  • Vibration resistant with a high tensile strength.
  • High temperature resistance.
  • Fast and handy to use.
  • Highly resistant to wear and vibrations.
  • Resistant to hydraulic oil, solvents, diesel fuel, petrol, salt water, battery acids, brake fluid, ...
  • High insulation resistance.
  • 3 transparent colour codes for various diametres with verification of the connection.
Article nr Name Content
T831001 Crimp & Seal connector red 100pcs.
T831002 Crimp & Seal connector blue 100pcs.
T831003 Crimp & Seal connector yellow 100pcs.
T831004 Crimp & Seal connector clear 100pcs.
T832041 Crimp & Seal ring red 4,2mm 100pcs.
T832042 Crimp & Seal ring blue 4,2mm 100pcs.
T832043 Crimp & Seal ring yellow 4,2mm 100pcs.
T832051 Crimp & Seal ring red 5,2mm 100pcs.
T832052 Crimp & Seal ring blue 5,2mm 100pcs.
T832053 Crimp & Seal ring yellow 5,2mm 100pcs.
T832061 Crimp & Seal ring red 6,4mm 100pcs.
T832062 Crimp & Seal ring blue 6,5mm 100pcs.
T832063 Crimp & Seal ring yellow 6,3mm 100pcs.
T832081 Crimp & Seal ring red 8,4mm 100pcs.
T832082 Crimp & Seal ring blue 8,5mm 100pcs.
T832083 Crimp & Seal ring yellow 8,5mm 100pcs.
T832101 Crimp & Seal ring red 10,5mm 100pcs.
T832102 Crimp & Seal ring blue 10,5mm 100pcs.
T832103 Crimp & Seal ring yellow 10,5mm 100pcs.
T833041 Crimp & Seal fork red 4,2mm 100pcs.
T833042 Crimp & Seal fork blue 4,2mm 100pcs.
T833043 Crimp & Seal fork yellow 4,2mm 100pcs.
T833052 Crimp & Seal fork blue 5,2mm 100pcs.
T833053 Crimp & Seal fork yellow 5,2mm 100pcs.
T834001 Crimp & Seal tab red M 100pcs.
T834002 Crimp & Seal tab blue M 100pcs.
T834003 Crimp & Seal tab yellow M 100pcs.
T835001 Crimp & Seal push red F 100pcs.
T835002 Crimp & Seal push blue F 100pcs.
T835003 Crimp & Seal push yellow F 100pcs.
T836001 Crimp & Seal bullet red M 100pcs.
T836002 Crimp & Seal bullet red F 100pcs.
T837001 Crimp & Seal bullet blue M 100pcs.
T837002 Crimp & Seal bullet blue F 100pcs.
T838101 Crimping Tool 1pc.
T838201 Assortment Case CRS 1pc. 1pc.

» To the shop
  • Technical data
  • Application and usage
  • Downloads

Insulation resistance: Megohms 103.
Dielectric resistance: 2,5 Kilovolt.
Chemical resistance: diesel fuel, brake fluid, antifreeze, 5% salt water, motor oil, ...
Solvent resistance: isopropyl alcohol, trichloroethylene, gasoline.

Constant temperature: from -55°C to 125°C.
Minimum shrink temperature: 180°C.
Voltage rating: 600 Volt maximum.
Shrink ratio: approximately 2:1.
Electrical properties: disruptive strength 1000 Volt;
insulation resistance: 103 Megohms.

  • garage and bodywork
  • built-in car radios and alarm systems
  • assembling of towing hooks
  • lorry and bus manufacturers
  • contract workers, farmers, earth-moving machines
  • signalisation and neon lights
  • horticulture and outdoor lighting
  • electric installation and maintenance services
  • repair of tools and machines
  • industrial maintenance services
  • motorbikes and mopeds
  • shipbuilding and -repair
  • amusement parks
pdf Product Information
techmasters_en_crs_PDS.pdftechmasters_en_crs_PDS.pdf (1.2 MB)
pdf Test Report IP67
techmasters_en_crs_TQ Test Report IP67 Crimp & Seal Connector_INFO.pdftechmasters_en_...nector_INFO.pdf (1.0 MB)
